manufacturer
Leonardo
configuration
VIP
condition
Used
year
2022
time
83
helicopter location
Brazil
serial number
22730
registration number
PS-TMA
listing ID
HT10347
Description
One Owner Since New
No Damage History
Only 83 hours - 123 landings
Training Slot for one pilot and one mechanic
Deliverd in Aug 2022
3 years or 2000 hours warranty
VIP Interior with full leather seats
213 USgal crash-resistant fuel system (in lieu of 152 USgal)
Baggage compartment extension (2.3 m)
Long step bar (LH & RH)
Enhanced Vision System (EVS) EVS-23000 Max-Viz
avionics
Dual Pilot IFR package (in addition to Single Pilot VFR STD configuration)
Dual Controls
Co-Pilot large colour Primary Flight Display (PFD) embedding:
Synthetic Vision System (SVS)
Highway in the sky (HITS)
Helicopter Terrain Awareness and Warning System (HTAWS)
Flight Management System (FMS)
Radio tuning controls
2nd VHF/AM
2nd VOR/ILS
2nd GPS
DME
Marker beacon
Electronic Standby Indicator
Co-Pilot Intercommunication System (ICS)
Dual Master warning lights
Dual Master caution lights
2nd Magnetic compass indicator
Digital Clock
Flight Director
Emergency Locator transmitter
Enhanced Vision System (EVS) EVS-23000 Max-Viz
Digital Map Euronav VII Euroavionics (The standard global package includes: Raster map data: Euroavionics outline map (basic detail), Euroavioncs Map 1:1.000.000, Vector map data: Euroavionics Overview map (basic detail), Terrain data: DTED 0, Database: Jeppensen NavData, Additional maps/options and any updates need to be ordered directly to Euroavionics by the customer)
Traffic Advisory System TAS-620 Avydine (Or equivalent model)
Weather Radar RDR 2000 Bendix/King (Or equivalent model)
equipment
Crash-resistant co-pilot seat, fore and aft adjustable, with lap belts and headrest
Shoulder harness with inertial reels (co-pilot)
AC power supply system (two [2] inverters)
AFCS 3-axis duplex SP-711 Honeywell
Radar Altimeter, Doors key lock, Airframe hour meter
Baggage compartment lights
Crew open door actuators
Two (2) engine compartment fire extinguishers
Fuel cap with key-lock
Pulsed chip detectors (In lieu of quick disconnecting chip detectors)
450 W Retractable/rotating landing light (nose mounted)
Reinforced windshield
Baggage compartment extension (1.9m)
Bleed air heater
Passenger foot step (RH)
Air conditioning ECU
Dual USB charger at central bench (RH)
Mast Vibration Absorver (MVA)
Cockpit access handle (RH)
Cockpit access handle (LH)
First aid kit
Baggage compartment extension (2.3 m)
Vertical baggage compartment door (in lieu of standard type)
Rotor brake
Windshield wipers (pilot and co-pilot) with wiper switch on cyclic grips
213 USgal crash-resistant fuel system (in lieu of 152 USgal)
Strobe lights on horizontal stabilizer
Long step bar (LH)
Long step bar (RH) (in lieu of standard passenger foot step (RH)
interior
Executive interior - 6 places
VIP Passenger cabin including: Sound proofing, liners leather or leatherette covered, Cabin loudspeakers (QTY. 2), Reading lights, advisory lights, floor courtesy lights, Upper and lower air vents, VIP Cabin finishing
VIP Cockpit package including: Interseat console tray with 12 V power supply, multipurpose holder (with space provision for fire extinguisher), door pockets (RH and LH), headset hooks (Qty 2), cyclic and collective leather gators, curtains in cockpit on upper windows, VIP Cockpit finishing
Three (3) crashworthy fwd facing seats (aft bench) covered with leather, with foldable armrest
Three (3) crashworthy aft facing seats (central bench) covered with leather, with see-through modification and with foldable armrest
4-Point shoulder harness with inertial reels and safety belts for all passenger seats
Cabin double layer acrylic windows (azure colored)
Headset Bose ANR type (Qty 6)
Floor carpeting
